Astralpool H5 Duo pool cleaner

Video

Automatic Pool Cleaner H5 Duo

• Ideal for pools of 80 m2
• For bottom, walls and waterline
• Gyro technology

This particular model is ideal for pools of 80 m2 and with it you will get a total cleaning of your pool: bottom, walls and waterline. Consult this table to see its most relevant characteristics.

Features of the H5 Duo pool cleaner

The robot model that we present to you has Gyro technology, an intelligent navigation system that guarantees the total cleaning of the pool. It does not coil up with the cable and avoids obstacles during cleaning.

With the height-adjustable suction nozzles you can obtain optimal suction. In addition, with the PVA brushes you will have an optimal grip to completely remove the dirt.

Here are some other features that make these robots high-end cleaners:

Three-dimensional filters

Get a more thorough clean with the ultra-fine 3D filter built into the robots.

LED indicator

You will always know how dirty the dust is. When the LED light comes on, you need to change the filter.

Easy view

The transparent windows of the cleaner allow you to see how dirty the robot is.

Easy open

Thanks to its easy opening, you can change the filter without complications and without getting your hands dirty because you don't need to be in direct contact with the filter to change it.

Advantages of the H5 Duo cleaner

• Improved power transmission.
• Effective oscillating brush.
• Lasts longer: no drive belts and improved motor seals.
• Enhanced capabilities: Gyro system + dual motor drive.
• Ease of repair: Direct access to gears and rollers.

What is the AquaSmart System

Traditional pool cleaners clean the pool by tracking the surface randomly and without any working pattern. With the introduction of the Aquasmart cleaning system, the cleaners are able to parameterize and memorize the pool surface through a mathematical algorithm, optimizing the operation and guaranteeing the brushing of the entire pool surface.

What is the Gyro System?

Gyro is an intelligent algorithm created by Aquatron to improve the robot's navigation and maximize its efficiency.

Main benefits:

• Efficiency on the surface to be cleaned.
• Programmed turning patterns to avoid cable entanglement.
• Created to improve the robot's navigation and maximize its efficiency, Aquatron has launched GYRO System the new intelligent algorithm.
• Located in the robot's management circuitry GYRO has the functions similar to an electrical gyroscope like the latest mobile devices.

Electric Robot Equipped with DUO System Motors

The Duo system is a set with 2 traction motors and a suction motor integrated in a sealed block.

Advantages

• More efficient cleaning
• Facilitates maintenance tasks
• Extends the life of your robot

Efficiency and performance, high-tech design for high reliability and durability.

Model Comparison

*Scroll horizontally to view the complete table.

	Supreme 4 Duo	Acuarius R4 - Logic Eco 40	H5 Duo	Acuarius R5 - Logic Eco 50	M4
Manufacturer	Typhoon	Dolphin	Astralpool	Dolphin	Dolphin
Soil	Yes	Yes	Yes	Yes	Yes
Wall	Yes	Yes	Yes	Yes	Yes
Waterline	Yes	Yes	Yes	Yes	Yes
Pool length	12 meters	12 meters	12 meters	12 meters	12 meters
Cleaning cycle	2 hours	2.5 hours	1,5 / 2 hours	2,5 hours	3 hours
AquaSmart	Yes	No	Yes	No	No
Gyro System	Yes	No	Yes	No	No
Third Cleaning Brush	Yes	No	Yes	No	Yes
Programmer	Yes	No	Yes	No	Yes
Floating cable	16 m	18 m	18 m	18 m	18 m
Anti-knot system	Yes	Yes	Yes	Yes	No
Trolley	Yes	No	Yes	No	Yes
Filtered water (m³/h)	22 m³/h	19 m³/h	22 m³/h	19 m³/h	17 m³/h
Filter Type	Fine and ultrafine	Fine and ultrafine	Ultrafine	Fine and ultrafine	Fine and ultrafine
Cleaning Brushes	PVA	PVC Mixed	PVA	PVA	PVC
Robot weight	8,2 kg	10 kg	8.2 kg	12 kg	9.2 kg
Traction motor	2	1	2	2	1
Suction motor	1	1	1	1	1
Remote control	No	No	No	No	No
Programming Settings	No	No	No	No	No
Warranty	3 Years	2 Years + 6 months	3 Years	2 Years + 6 months	2 Years
Price	899 €	950 €	1299 €	1090 €	975 €

SKU Referenced:

• 66016

Warranty Information

3 years from the manufacturer according to Royal Decree Law 7/2021, April 27.

*The correct operation of the equipment can not be guaranteed both in the bottom and in the rise of walls whenever the pH level is not correct, contains slime or algae or filters are clogged by excess dust, and has not been previously made a total cleaning of the vessel, in addition to any pool with irregular surfaces on the walls such as steps or ribs *.
