Gre inverter heat pump
Gre heat pump with Inverter technology which makes it more efficient, saves consumption and low noise compared to other pumps.
Available in 4 models that adapt to pools up to 85 m³.
Manuals
Gre Inverter Heat Pump Gre Inverter Heat Pump Instruction Manual
Gre Inverter Heat Pump
The Gre heat pump with Inverter technology is able to adjust the heating capacity automatically according to the heat demand.
- High efficiency that allows to reach an optimal COP (coefficient of performance).
- Minimal power consumption. Savings in electricity consumption compared to a standard heat pump.
- Less noise. The Inverter heat pump operates at a significantly lower decibel level than a standard heat pump.
- High durability. Titanium heat exchanger and high resistance casing.
- Operating temperature from 7°C.
- Automatic defrosting.
| Model | HPGI50 | HPGI60 | HPGI70 | HPGI85 | |
| * Air capacity 28℃ / water 28℃, Humidity 80%. | |||||
| Heating power | kW | 10-2,3 | 12-2,9 | 15-3,2 | 17-3,8 |
| Power consumption | kW | 1,55-0,14 | 1,77-0,18 | 2,26-0,2 | 2,67-0,23 |
| COP | 16-6,5 | 16-6,8 | 16-6,6 | 16-6,4 | |
| * Air capacity 15℃ / water 26℃, Humidity 70%. | |||||
| Heating power | kW | 7-1,9 | 8,5-2 | 10-2,2 | 12-3 |
| Power consumption | kW | 1,43-0,27 | 1,72-0,28 | 2,07-0,31 | 2,43-0,42 |
| COP | 7,1-4,9 | 7,2-4,9 | 7,2-4,8 | 7,2-4,9 | |
| General Characteristics | |||||
| Compressor | Inverter | ||||
| Voltage | V | 220~240V / 50Hz / mono | |||
| Maximum volume of the pool ** | m³ | < 50 | < 60 | < 70 | < 85 |
| Recommended water flow rate | m³/h | 2,8 | 3,7 | 4,0 | 4,6 |
| Water pressure drop | KPa | 12 | 14 | 15 | 15 |
| Heat exchanger | Twist-Titanium tube in PVC | ||||
| Water inlet-outlet connection | mm | 50 | |||
| Type of ventilation | Horizontal | ||||
| Degree of protection | IPX4 | ||||
| Maximum pressure discharge and suction side | MPa | 4,2 | |||
| Noise level (at 10 meters) | dB(A) | 22-34 | 23-35 | 23-37 | 24-37 |
| Noise level (at 1 meter) | dB(A) | 40-52 | 40-52 | 40-54 | 41-54 |
| Refrigerant | R32 | ||||
| Refrigerant quantity | g | 720 | 550 | 750 | 850 |
| CO2 equivalent | Tm | 0,49 | 0,37 | 0,51 | 0,57 |
| Net weight | kg | 56 | 68 | 73 | 78 |
| Gross weight | kg | 68 | 73 | 78 | 83 |
| Dimensions | mm | 860 x 389 x 586.5 mm | 987 x 400,5 x 688 | ||
| Packing dimensions | mm | 890 x 420 x 625 | 1015 x 435 x 713 | ||
** Ambient temperature of 15ºC, water temperature of 26ºC and humidity of 70%.
Warranty information
3 years from the manufacturer according to Royal Decree Law 7/2021, April 27th.
Attention
Piscinas Ferromar recommends a previous thermal study to determine the equipment and power that best suits your pool and needs, taking into account the location, use of the pool, desired temperature, etc... To do so, please contact us at info@piscinasferromar.com and we will send you the most suitable solution. If you choose to purchase the heat pump without a previous thermal study, Piscinas Ferromar is not responsible for its performance to suit the specific needs of the customer and the installation. Important: heat pumps require outdoor installation and must be installed and commissioned by a professional.
-
